I-160 is based on an electromagnetic pulse method which can be used to select anomalies in the
target area. Thus the device is able to detect natural features such as formations of strata,
cavities, groundwater level as well as sepulchers or buried objects such as pipes, tanks,
boxes or suchlike.
I-160 is a professional device with a sixteen fold better Resolution in comparison to the Rover
and Walkabout devices. Because of the compact probe it's not only suitable for usage in flat
grounds. Besides the normal graphic representation this device offers two further specialities.
First there is a horizontal live graphics that shows buried objects immediately on screen.
Second you can make a typified ultrasound graphics.
Because of the integrated microprocessor technology ground balance, measuring of depth and data
storage will be performed automatically by the device. The evaluation take place at the computer
where the scanned area can be analyzed in a three-dimensional graphic.
Technical Specification:
- 12V power supply
- 9,35 GHz scan frequency
- Dimensions: approx. 170 x 200 x 65mm
- Weight: approx. 1500g
- Maximum deep: 18m
Tested and certified by one of the
leading technical experts in Germany
Compliance with the CE policies
Data transmission via Bluetooth
Depth measurement up to 18 m depends on object size and ground conditions.
Scope of delivery: I-160
- 1 3D software ( standard )
- 1 Carrying case
- 1 Control chip
- 1 Control unit
- 1 External power supply with charger and cable ( 12V )
- 1 Headphones
- 1 Horizontal probe with 16 sensors
- 1 Linkage
- 1 Ultrasound probe with 16 sensors ( 3m )
- 1 USB bluetooth dongle + setup CD
- 1 User manual
- 1 3D software ( "Visualizer 3D" ) - optional
