The eXp 5000 is a measuring instrument of newest technology and has been developed in particular for professional use. Through the supplied video eyeglasses buried objects like boxes, pipes, metals but also cavities and grave chambers under the surface becomes visible immediately. Further more the video eyeglasses are optimised for the search during the night and also protects against perturbing sunlight at day.
The eXp 5000 includes an easily removable control unit with carrying strap which makes it easier to use in different areas. With its compact equipment the device is also easy to handle in terrains which are difficult to access.
The device allows measurements in brilliant resolutions up to a depth of 25m. All recorded data is processed immediately through the integrated pc-module and becomes visible through the video eyeglasses. The amount of possible measurements is almost indefinite and only limited by the storage capacity of 64 MB. All collected measured data can be transferred afterwards to a computer to analyse the results professionally in a 3d software program. To every graphical representation date and time are saved automatically and can be adapted individually to the actual time zone.
The integrated GPS receiver refers every recorded measurement to its appropriate measured area. The GPS system can also be used to navigate to any coordinates you like.

Optional accessories as specialization
With different antennas the eXp 5000 can be optimized on special purposes:
- GPR-antenna (25cm, 50cm, 75cm, 100cm)
- Antenna for metal discrimination
- Antenna for tunnel and cavity detection
- Super Sensor for high resolution ground scans
- VLF sender (4 pieces)

VLF sender
A large area can be scanned by positioning the 4 VLF sender on the ground. The search for metallic objects will be optimised.

Technical Specification:
- Power supply: 12 Volt
- Weight: about 2 kg
- 57.800 impulses per second
- Working memory: 64 MB SDRAM
- Data memory: 128 MB
- Voltage: 9.6 - 14.4 VDC, 22W maximum
- Safety class: IP 40
- Operating time (full charged battery, delivered power supply, 25°C) about 3 hours
- Operating temperature: 0°C - 40°C
- Display: 640 x 480 Pixel TFT color
- Computer: 300 MHz Processor, INTEL i586- kompatible
- Feedback: audible, visual
- Maximum deep: 25m


Tested and certified by one of the leading technical experts in Germany
Compliance with the CE policies
Data transmission via USB
 Depth measurement up to 25 m depends on object size and ground conditions.
